High-temperature and inorganic coating binders
Two water-based binders for coatings that need to survive heat, damp underground environments or fire. Both are zero-VOC.
GHNK inorganic high-temperature binder
- Composition
- Inorganic compound
- Appearance
- Transparent liquid with a blue tint
- Solids
- 28–30 %
- pH
- 9–10.5
- Properties
- Heat resistant, strong adhesion and bonding, good water resistance
- Uses
- Heat-resistant coatings, purely inorganic coatings, coatings for underground spaces and tunnels, road-marking paint, other zero-VOC speciality coatings
- Storage
- 1–35 °C; shelf life over 12 months
- Packaging
- 140 kg drums, or to order
Starting formulation: heat-resistant coating
| Component | Parts by weight | Component | Parts by weight |
|---|---|---|---|
| GHNK | 45–50 | Talc | 5–10 |
| Water | 10 | Mica powder | 10 |
| Dispersant | 0.8 | Kaolin | 10 |
| Wetting agent | 0.5–1 | Levelling agent | 2 |
| pH adjuster | 0.2 | Cellulose thickener | 0.2–0.4 |
| Titanium dioxide | 15 | Preservative | 0.1 |
Starting formulations are guidance only and are not suitable for every application. Trial the product in your own system before production use.
CH-1304 polymer-modified nano silica sol
- Composition
- Nano-scale silica sol modified with a polymer
- Appearance
- Hazy white, translucent liquid
- Solids
- 27 ± 1 %
- pH
- 8.0–9.5
- Properties
- Improves adhesion, hardness and abrasion resistance when added to metal, wood and architectural coatings. Zero VOC and zero formaldehyde.
- High temperature
- Used in heat-resistant coatings rated for about 1000 °C, and as the base for thick fire-retardant coatings
- Storage
- 5–35 °C, ventilated, out of direct sunlight; shelf life 6 months
- Packaging
- 140 kg plastic drums, or to order
Starting formulations for inorganic wall coatings and inorganic–organic stone-effect coatings are available on request.
CH-1305 and CH-1566 modified nano silica sols
| CH-1305 | CH-1566 | |
|---|---|---|
| Composition | Modified nano-silica sol polymer | |
| Appearance | Pale yellow, transparent liquid | |
| pH | 8.0–9.5 | 8.0–9.5 |
| Solids | 27 ± 1 % | 28 ± 1 % |
Added to metal, wood and architectural paints, they increase adhesion, hardness and abrasion resistance. They are used in heat-resistant coatings rated for about 1000 °C, as the base for thick fire-retardant coatings, and in exterior and interior inorganic wall coatings. Zero VOC and zero formaldehyde. CH-1566 is the more widely used of the two and gives coatings better storage stability. Packaging: 140 kg drums; shelf life 6 months at 5–35 °C.
GHS1368 inorganic silicon resin
- Composition
- Modified nano-silica sol polymer
- Appearance
- Pale yellow, transparent liquid
- pH
- 9.0–10.0 (keep the pH in this range; it is not stable outside it)
- Properties
- Low VOC, low combustibility, high hardness, high adhesion
- Uses
- Exterior and interior inorganic wall coatings; Class A fire-retardant coatings
- Packaging
- 140 kg drums or 1000 kg IBC, or to order
- Storage
- 5–35 °C indoors; shelf life 6 months
Fire-retardant coatings
Inorganic binders do not burn and do not release toxic halogenated smoke. That is why they are used as the base of fire-retardant coatings for timber, steel and building boards. CH-1304, CH-1305 and CH-1566 are used as the base for thick fire-retardant coatings, and GHS1368 is designed for Class A fire-retardant coatings. In research, silica sols are also combined with phosphorus and boron fire retardants to fix them in timber and improve their water resistance.
Every fire-retardant coating must be tested and certified as a finished system to the standard that applies in your market, such as EN 13501-1 or ASTM E84. We supply the inorganic binder and work with your formulators on the system.
Frequently asked questions
GHNK or CH-1304: which should I use?
Do these binders contain VOC or formaldehyde?
Can they be used in damp environments such as tunnels?
Need the full TDS or a trial sample?
Tell us your application and target spec. Our technical team replies within one working day.
